Blue Sea BatteryLink Automatic Charging Relay 12/24vDC 120A

Blue Sea BatteryLink Automatic Charging Relay 12/24vDC 120A

Blue Sea Systems
SKU:
BSS7611
|
UPC:
632085076115
$106.05
$121.95
(You save $15.90 )
(No reviews yet)
Condition:
New
Current Stock:
Adding to cart… The item has been added
Description

Blue Sea Systems BatteryLink™ Automatic Charging Relay - 12V/24V DC 120A

Model: 7611-BSS
  • 120 Amp continuous rating
  • 12/24V DC auto ranging voltage input
  • Senses charging on two battery banks
  • Side and bottom knockouts for cable connections
  • Clip-on cover insulates terminal connections
  • 7/8" (22 mm) stud length to accept multiple cable terminals
  • Integrated LED indicates ACR status
  • 1/4" .032" male quick connect terminals for ground and optional features
  • Largest battery bank cannot exceed Group 27

Automatically shares single source of charge with Auxiliary Battery

Specifications
Nominal Voltage12V DC
24V DC
Auxiliary Battery PriorityYes
Amperage Operating Current175mA @ 12V (Combine) 115mA @ 24V (Combine) 15mA (Open)
Continuous Rating120A
Intermittent Rating210A (5 min)
Maximum Cable Size1/0 AWG
Maximum Torque140 in-lb (15.82 Nm)
Stud MaterialTinned Copper
Terminal Stud Size3/8" - 16 (M10)
